Surly Moonlander Fat Tire Bike - 24" Steel Lunar Dust Gray Small

$4,199.00
$4,199.00
$4,199.00

Questions about sizing, geometry, or custom builds? Give us a call (831) 215-1784

SKU: BK00443

Expected Ship Date: Wed Sep 23
30-Day Hassle-Free Returns
Bike Returns & Exchanges: We offer returns and exchanges on bikes. Customers are responsible for return shipping, but we do not charge a restocking fee.
Description
Surly Moonlander Fat Tire Bike - 24" Steel Lunar Dust Gray Small. Designed to go where no normal fat bike can the Surly Moonlander is for riders who want otherworldly capabilities on rocky shorelines sand snow and desolate landscapes not yet discovered. While our proprietary 24 x 6.25" tires surpass the limitations of current fat bikes the Moonlander still rides like a normal bike making it easier (and more fun) to navigate previously unrideable terrain. It’s the ultimate choice for explorers who itch for the next great adventure and aren’t afraid of what they might find.
  • Constructed from 100% Surly Chromoly Steel for excellent durability
  • Surlys first bike with a 9-speed Pinion gearbox an innovative approach to spur gearing that improves reliability and go-anywhere performance with less maintenance
  • Large volume Surly Molenda Tires on 24 x 100mm Surly Clown Royal Rims creates footprint large enough to float over unpredictable terrain
  • Clearance for 24 x 6.25" tires as well as 26 x 5.1" 27.5 x 4.8" and 29 x 3"
  • Comes with rack and fender mounts as well as accessory mounts on both fork blades to enhance cargo capacity
  • Weight distribution across front and rear with a longer back allows for greater stability
  • Features Tektro HD-M285 Hydraulic Disc Brake System
  • Four frame sizes to fit most riders: SM MD LG XL
  • Includes a dropper for easier on and off especially on soft surfaces
    • TECH SPECS
    Rear Axle 12mm Thru x 197mmBrake Type DiscTT (Effective) 575Fork Type RigidFork Material SteelFrame Material SteelFrame Type RigidFront Axle 12mm Thru x 197mmColor Lunar Dust GrayMfg Size SmallPlatform MoonlanderWheel Size 24"Defined Color Gray

    Build Kit

    Specifications subject to change without notice.

    Frameset

    Frame Surly Moonlander Frame - 100% Surly Chromoly steel, E.D. coated, triple-butted main triangle, TIG-welded
    Color Lunar Dust Gray
    Fork Surly Moonlander Fork - 100% Surly Chromoly steel. 1-1/8" straight steerer with tapered straight blade, TIG-welded, E.D. coated. 51mm IS front standard disc mount. 197mm x 12mm thru-axle dropouts (axle included).

    Components

    Headset Cane Creek 40
    Seatpost Clamp Surly Stainless 33.1mm
    Seatpost TranzX YSP15JL Dropper, 125mm travel (100mm travel on SM)
    Stem Promax, 31.8, 4-bolt
    Grips/Bar Tape Velo Lock-On
    Saddle WTB Volt Medium

    Drivetrain & Brakes

    Gearbox Pinion C1.9 XR, 9-speed
    Shifter Pinion Rotary Shifter
    Crankset Pinion for Surly crankset 34T, with Pinion high-offset spider
    Chainring FSA Steel 36T Megatooth
    Chain KMC X10 EPT Anti-Rust
    Brakes Tektro HD-M285 Hydraulic Disc
    Gross Payload 242 lb (110 kg) max. rider + cargo (Pinion limitation)

    Wheels & Tires

    Front Tire Surly Molenda 24 x 6.2", 60tpi, Tubeless Ready
    Rear Tire Surly Molenda 24 x 6.2", 60tpi, Tubeless Ready
    Front Hub Novatec 12x197mm, Thru-Axle, 32h
    Rear Hub Novatec 12x197mm, Thru-Axle, 32h
    Rim Surly Clown Royal 24", 100mm wide


    Product Images Disclaimer
    Product images are for reference only and may not reflect the exact specifications, color, or components of the item offered for sale. Please refer to the product description and specifications for the most accurate details. If you have questions before purchasing, contact us, and we’ll be happy to confirm.
