To suit tapered forks
If you are running a 1 1/8" fork you will need to purchase the Works Components reducer crown. - this headset comes as standard with a crown race to suit tapered forks
Upper cup Stack height: 11mm - Total upper stack height including bearing cover: 16mm
Lower cup Stack height: 14mm
Upper Bearing: 41mm OD, 45 x 45 Degree AC sealed bearing
Lower Bearing: 52mm OD, 45 x 45 Degree AC sealed bearing
Upper cup insertion depth: 9mm
Lower cup insertion depth: 10.5mm
Split type 7075-T6 aluminium crown race for simple, tool free installation
Headset comes complete with top-cap (star-nut included), bearings and crown race - all parts required for fitment
| Bearing Grade |
ACB Sealed |
| Headset Type |
External Threadless |
| SHIS Upper |
EC44/28.6 |
| Crown Race Diameter |
44mm |
| Misc |
Headtube length 100-109mm |
| S.H.I.S. |
EC44/28.6 | EC44/40 |
| Angle |
1.5° |
| Material |
7075-T6 Aluminum |
| SHIS Lower |
EC44/30 |
| Stack Height |
16 |
| Upper Cup |
44mm |
| Headset Position |
Complete |
| Lower Cup |
44mm |
| Primary Color |
Black |
Product Images Disclaimer
Product images are for reference only and may not reflect the exact specifications, color, or components of the item offered for sale. Please refer to the product description and specifications for the most accurate details. If you have questions before purchasing, contact us and we’ll be happy to confirm.
